CPi-S101WR (10.1" Industrial Raspberry Pi Touch Panel PC)

The ComfilePi is a Raspberry Pi-based industrial touch panel PC.

• Broadcom BCM2711, Cortex-A72 (ARMv8) 64-bit SoC @ 1.5GHz (Compute Module 4S)
• 10.1" LCD (1024 × 600) (500 candela)
• Pressure-sensitive Touch Screen (Resistive Film Type)
• 1GB RAM
• Built-in RTC
• GPIO x 22 (includes ESD protection circuit), 40-pin header socket
• Power: DC12 ~ 24V input
• USB ports x 3 (USB2.0)
• Ethernet port (10/100 Mbps)
• RS-232C x 1
• RS-485 x 1
• I2C x 1
• Electro-magnetic Buzzer
• Stereo Audio Output
• Water-Resistant Front Panel (IP65)
• WiFi: USB dongle required
• Operating temperature: 0°C ~ 60°C
• Storage temperature: -20°C ~ 80°C

Please review the revision history.

To migrate an existing CPi-A/B solution to the CPi-C/S panel PCs, please see our migration documentation.

 ComfilePi User's Manual

Regulatory Compliance (CE, KCC, UL)

An SD card is not included if ordered with an eMMC.

A USB-A to USB-A cable is required to reprogram the eMMC, but is not included.
