MSB642RA-DC

The MSB series is an industrial computer based on CUBLOC. It can be programmed using both the BASIC language and ladder logic. Like a typical compact-sized PLC, it can be directly installed and wired at industrial sites.

• Certifications :
• 24 24VDC Inputs, 18 built-in 10A Relays
• 4 0~10V Analog Inputs (5-pin Molex 5264 connector included)
• 4 0~20mA Analog Inputs (5-pin Molex 5264 connector included)
• 2xRS232 Port (4-pin Molex 5264 connectors included)
• 1xRS485 Port (5-pin Molex 5264 connector included)
• 2 High-Speed Counters
• Powered by 24VDC
• No Real-Time Clock

** 3-Pin Download Cable required **

Includes

• 4-pin cable x 2
• 5-pin cable x 3 (length 25cm)

 MSB User's Manual

 CUBLOC User's Manual

Certificate (CE, KCC, FCC)
