CPCV6-150WF (15" INTEL Celeron J6412 Quad 2GHz Touch Panel PC)
- SKU:
- W04414
- Shipping:
- Calculated at Checkout
Description
Get Windows desktop functionality in a touch pane PC. COMFILE Technology's Windows 10/11 Touch Panel PCs feature desktop functionality, yet are designed to withstand the harsh environments typical of industrial applications.
- Screen Size : 15" (1024 x 768)
- Processor : Intel Celeron J6412 / Quad Core 2.0 GHz
- System Memory : 4G DDR3 RAM
- Touchscreen: Resistive
- HDD : 128GB m-SATA (FLASH Hard Disk)
- OS (option) : Windows 10 IoT Enterprise, Windows 11 Home / Pro
- Etc : 2x2.5Giga Ethernet, 4xUSB, 3xRS232, 1xRS232/422/485
- Water-resistant Front Panel (IP65)
CUPC CPCV6 series User's Manual
| CPU | Intel Celeron J6412 | ||||
| Core Number | Quad | ||||
| Clock Speed | 2.0GHz | ||||
| CPU Type | Onboard | ||||
| Memory | SODIMM DDR4 4GB | ||||
| HDD | m-SATA 128GB | ||||
| Graphics | Intel UHD Graphics | ||||
| Video I/O | 2 x DP Output Port | ||||
| Ethernet | 2 x 2.5 Gigabit Ethernet | ||||
| Audio | Realtek High Definition Audio | ||||
| Audio I/O | 1 x Audio Line Output | ||||
| USB | 2 x USB3.2 Gen2x1 Type-A, 2 x USB2.0 Type-A | ||||
| Serial | 1 x RS232C/RS485, 3 x RS232C | ||||
| Power | |||||
| Input Power | +12VDC | ||||
| Power Consumption | 16W (1.3A@DC12V) | ||||
| Mechanical | |||||
| Dimensions(WHD) unit:mm | 376x300x79 | ||||
| Housing | Front:ABS,Rear:Steel | ||||
| Weight | 4.05Kg | ||||
| Environment | |||||
| Operation Temperature | 0oC~60oC | ||||
| Operation Humidity | 5~90%RH@60oC | ||||
| Storage Temperature | -30oC~80oC | ||||
| Storage Humidity | 10~90%RH@60oC | ||||
| Certification | |||||
| EMI Certification | |||||
| Software | |||||
| Operating System | Windows 10 IoT Enterprise 2021 LTSC (64 bit) | ||||
