CUBASE-40M

This is a feature-rich relay I/O base board designed for use with the CUBLOC CB400 and CB405 core modules. While using a CUBLOC core module typically requires designing a custom PCB—often a barrier for beginners— the BASE Board eliminates this complexity by allowing the core module to be installed directly onto a ready-made industrial PCB.

With all essential I/O circuitry already integrated, the BASE Board can be deployed immediately in industrial environments. It is ideal for control panels, machine control, and automation systems where fast setup, reliable I/O handling, and proven hardware design are required.

The board combines opto-isolated digital inputs, relay outputs, analog input circuits, high-speed counter inputs, and PWM outputs on a single platform, providing a versatile foundation for a wide range of industrial control applications.

• 24 opto-isolated digital inputs (24 V input via photocoupler)
• 16 relay outputs
• 4 analog input circuits
• 2 high-speed counter input circuits
• 3 PWM outputs

Dimension
