Parts & Field I/O

Enclosure for CB210 (Arduino)    CUBLOC CB210 enclosure CAD files

This product is used to extend I/O capabilities of the ComfilePi+CODESYS or as a companion to the ComfileHMI, but can also be used as a Modbus slave for any RS-485 Modbus capable application. No programming required!  Just connect a Modbus...

This product is used to extend I/O capabilities of the ComfilePi+CODESYS or as a companion to the ComfileHMI, but can also be used as a Modbus slave for any RS-485 Modbus capable application.  No programming required!  Just connect a...

The main module board comes in a 10 slot configuration. If 10 slots are insufficient, a 5-slot extension board can be connected to the 10-slot board to increase the capacity for additional modules.  MOACON 5Slot, 10Slot CAD files

If your requirements only require five modules or less, the 5 slot extension board can be used independently as a main board. Includes ribbon cable and terminator.  MOACON 5Slot, 10Slot CAD files

The PT100Ω is a temperature sensor widely used in the industrial field because it can measure a wide range of temperatures from -100 to +500 degrees Celsius. The ML-THRT1 module converts the resistance value of the PT100Ω sensor to a digital...

PT100Ω sensor (3 line) RS-THRT4, ML-THRT1 (Temperature Input Module) with use. Length : 6.56 ft (2m)

RS232 TO RS485 Convertor   CN-RS232485 User's Manual  CUBLOC CN-RS232485 CAD files

10A Relay 8 Point Board. 10A HANKUK Relay DIN-Rail Attachable   HR-CR7DC24 Datasheet  RH8 Relay Board CAD files

You can connect the adapter jack to the terminal block as it is.       There is also a way to cut the end of the cable and connect it directly, so you do not have to buy this product.

PLUG IN ADAPTOR 12VDC 1.5A UNR 120VAC IN

Switching AC-DC ADAPTOR 120VAC IN, 24V 1.05A output If you want to use it on a terminal block, cut out the ends and connect them as shown in the picture below. At this time, you should watch the polarity and connect.

Switching AC-DC ADAPTOR 120VAC IN, 24V 1.05A output with DC jack dongle

S.M.P.S. Input: 85~264V Output: DC24V 1.1A  UL Certification [JSF25 Series]  MSF15-24 CAD files

This product converts the I/O connector at the back of CT1721C to terminal-block style, to provide easy access to external devices.

RS232C 3-PIN Download Cable for CUBLOC MSB series.

RS232C 9Pin 1:1 Cable for connect PC with CUBLOC.

3-Pin Download Cable with USB-to-RS232C Cable Download for MSB Serise   USB-to-RS232C Cable Driver (Prolific chipset)

MOACON / CB210 USB cable for downloading. This product is included in the START PACK.  Length : 6 ft (185cm)
